| pos |
Description |
art.no |
qty |
| 1 |
Anti tip device basket 33 |
4370033 |
1 |
| |
Anti tip device basket 36 |
4370036 |
1 |
| |
Anti tip device basket 39 |
4370039 |
1 |
| |
Anti tip device basket 42 |
4370042 |
1 |
| 2 |
Wheel-tube anti-tip basket compl. |
4370021 |
1 |
| 3 |
Tube, anti tip, 33 |
4370233 |
1 |
| |
Tube, anti tip, 36 |
4370236 |
1 |
| |
Tube, anti tip, 39 |
4370239 |
1 |
| |
Tube, anti tip, 42 |
4370242 |
1 |
| 4 |
Casterfork anti-tip basket compl. |
4370020 |
1 |
| 5 |
Wheel tube, anti tip, basket |
4370002 |
1 |
| 6 |
Antitip wheel basket |
2404003 |
1 |
| 7 |
Wheel anti-tip basket |
4370005 |
1 |
| 8 |
Hinge Clamp double |
4601116 |
1 |
| |
Clamp Pin outer double |
4601113 |
1 |
| |
Hinge clamp inner |
4601111 |
2 |
| |
Springy Tube-pin 3x26 |
9000326 |
2 |
| 9 |
Quick-Release |
4250007 |
1 |
| 10 |
Bearing |
2000021 |
4 |
| 11 |
Spacer anti-tip basket |
4370004 |
2 |
| 12 |
Socket plastic, basket |
4370001 |
1 |
| 13 |
Bushing anti-tip basket |
4370003 |
1 |
| 14 |
Endplug, IKP 19-15/17, black |
9000330 |
1 |
| 15 |
Bolt M6S 8.8M8x45 fzb |
6001845 |
1 |
| 16 |
Lock nut DIN 985 steel M8 fzb |
7000080 |
1 |
| 17 |
Bolt, MLC6S M6x40 fzb |
6002640 |
1 |
| 18 |
Washer, BRB steel 6.4x12 fzb |
8000612 |
9 |
| 19 |
Washer, M8 |
8000816 |
1 |
| 20 |
Washer, BRB steel 4,3x9x0,8 fzb |
8000409 |
1 |
| 21 |
Screw RXS 4,2 x 9,5 |
6005611 |
1 |
| 22 |
Screw, RXS B6x9,5 |
6005609 |
3 |
| 23 |
Nut DIN 439 B steel M8 fzb |
7000082 |
1 |
| 24 |
Lock nut, DIN 985 steel M6 fzb |
7000060 |
1 |
| 25 |
Clamp basket anti tip 28 |
4370011 |
2 |
| 26 |
Clamp basket anti tip 19 |
4370010 |
2 |
| 27 |
Bolt, MC6S M6x65, fzb |
6002665 |
8 |
| Bolt, MC6S 8.8 M6x75 fzb |
6002675 |
8 |
| |
|
|
|
| |
Position 27 depends what camber your rear axle has: |
|
|
| |
|
|
|
| |
Camber 10 degree - Bolt with art.nr 6002665 |
|
|
| |
Camber 12 degree - Bolt with art.nr 6002665 |
|
|
| |
Camber 14 degree - Bolt with art.nr 6002675 |
|
|
